Yoke 5T

Material Handling System for Various Mass Timber Panels
  • Manufacturer
  • MTC Solutions

Request a Quote Tech. Support

Simple Installation

CLT

Glulam Beam

Comply with OSHA

Product Description

Product Description

The Yoke 5T is a heavy-duty rigging system designed and tested for lifting mass timber elements such as CLT floor, roof, and wall panels.

The Yoke 5T anchor is fastened onto the rigged element using four Partially Threaded ASSY Kombi self-tapping screws, allowing for an easy and precise installation without the need for pre-drilling. The self-tapping screws used with the Yoke 5T system are ICC-ESR approved in the United States and CCMC (Canadian Construction Materials Centre Reports) code-approved in Canada.



Features

  • Installed with ICC-ESR approved 1/2” [12 mm] diameter ASSY Kombi structural self-tapping screws
  • OSHA compliant in the USA
  • IHSA compliant in Canada
  • Specially designed to lift:
    • Mass timber CLT roof and floor panels
  • Fast & easy installation allowing for efficient truck unloading sequencing
  • Lightweight and easy to transport
  • Capacity-rated strength
  • Powder-coated finish

Following the guidelines in our Rigging Design Guide, and with a well-designed truckload sequencing, four Yoke 5T anchors can lift heavy timber members of up to 13,000 lb into place while noticeably increasing rigging efficiency.

Design Guides

Design Guides

Rigging Design Guide

A step-by-step guide to lift all engineered wood products available in North America using MTC Solutions OSHA & IHSA compliant solutions. Do it right, do it safely!

Installation Instructions

Installation Instructions


Yoke 5T Installation


Learn how to install MTC’s Yoke 5T, OSHA & ISHA compliant rigging devices used to safely lift various Mass Timber floor/roof panels (CLT/NLT/DLT).
