MTS-i 40

MTS-i 40 Mass Timber Strap
  • Manufacturer
  • MTC Solutions
  • Connection Type
  • Wood/Wood
  • Applications
  • Mass & Heavy Timber Constructions

Request a Quote Tech. Support

Fast Installation

Mass Timber System

Performance-Based Design

Product Description

Product Description

The MTS-i Mass Timber Strap series offers two solutions: the MTS-i 40 and the MTS-i 30 series. The MTS-i 40 is a tested high-capacity connection specifically designed for tension applications in Mass Timber construction.

By using high-strength inclined screws, the MTS-i 40 offers higher stiffness and can be installed in various tension applications such as diaphragm connections & reinforcement, and wall-to-wall connections. The MTS-i 40 is fastened onto timber elements using 5/16″ x 8-5/8″ [8 x 220 mm]  diameter Fully Threaded  ASSY VG CSK self-tapping screws and 45-degree washers, which allow for an easy and precise installation onto timber elements without the need for pre-drilling.

Features

  • Installed with inclined code-approved 5/16” [8 mm] diameter ASSY VG CSK structural self-tapping screws & 45-degree washers
  • Engineered with high strength steel
  • Capacity-rated strength
  • Powder-coated finish
  • Detailed capacities and system behavior available in the MTC Solutions Connector Design Guide

The self-tapping screws used with the Mass Timber Strap system are ICC-ESR code-approved in the United States, and CCMC  approved in Canada. By using high-strength inclined screws, the MTS-i 40 offers higher stiffness and capacity for various tension applications, making it a one-of-a-kind off-the-shelf connecting solution.

CAD Drawings

2D & 3D Geometry

ProductFile Extension
.DXF .DWG.IFC.STEP.RFA
MTS-i 40
Design Guides

Design Guides

Connectors Design Guide

Learn how to design essential Mass Timber systems with MTC Solutions’ connectors, tested and engineered for the North American market.
