MEGANT Installation Guide

What is the MEGANT Installation Guide and who is it for?

This guide supports field installers, site foremen, and fabrication teams working with MTC Solutions’ MEGANT concealed beam hanger systems. It provides all necessary installation steps, fastener charts, and tool recommendations to complete your install successfully.

The layout is simplified for quick referencing with a black-and-white format – ideal for clipboards and printouts.

What hardware and tools do I need to install a MEGANT?

For an accurate installation of MEGANT, MTC recommends:

• A low-RPM, high-torque drill with a feathering trigger for enhanced speed control.
• RW 40 bits for optimal torque transmission.
• A 1/4 in. pre-drilling jig for accurately located pilot holes.

Want to know more about the pro tools for mass timber install? Read our article on the topic.

What hardware comes with MEGANT systems?

Each MEGANT connector set includes all the necessary components for secure installation:

• 2 identical aluminum connector plates
• 2 clamping jaws (one threaded, one unthreaded)
• 1-to-3 threaded rods (M16 or M20, depending on the model)
• 1-to-3 hexagonal nuts and washers (based on model specifications)
• VG CSK screws for each plate

The quantity of fasteners and estimated installation time vary depending on the specific MEGANT model.

Where can I find full technical specs and design support?

Need full-capacities, code references, fire design details, or housing guidance? Access the Beam Hanger Design Guide.

Is this guide printable and field-ready?

Yes. Click, download, print, and use.
